MAIN MOVING SYSTEM 2-29
MAIN MOVING SYSTEM
CAMSHAFT, HLA, TIMING CHAIN, CHAIN GUIDE
COMPONENTS
L4GC043A
Tightening torque : kg·m
HLA
T : 0.8~1.0
T : 0.8~1.0
Center cover
Cylinder head cover
Gasket
Bearing cap(rear)
Chain guide
Exhaust camshaft
Intake camshaft
Camshaft oil seal
Bearing cap(front)
Camshaft sprocket
T : 10~12
T : 0.25~0.35
