CHARACTERISTICS OF THE "LEOPARD" ENGINE - OPERATIONAL LIMITS
1. The characteristics of the engine are the following :
• Cycle: OTTO / 2 stroke
• Original cubic capacity: 123.7 cc
• Original bore: 54.00 mm
• Max. theoretical bore: 54.28 mm
• Stroke: 54.00 mm
• Lubrication : Fuel-Oil mix
• Induction: Reed valve
• Carburetor: Membrane , Tillotson
• Cooling : water
• Ignition: Digital / 4 poles with internal rotor
• Battery charge: With integral generator
• Electric start: 12V/0.30 Kw
• Clutch: Automatic, dry, centrifugal
2. OPERATIONAL LIMITS:
• Max. RPM : 15000 RPM
• Min. waterTemperature: 45°c
• Max. water Temperature: 90°c
ATTENTION:
Never exceed the above limits, no obligation of IAME exists in case the above
limits are exceeded.
