iBaby M2C - Product Overview; Packing List; Interface Introduction

iBaby MonitorUser Manual
3
1
Product Overview
1.1 Packing list
 iBabymonitor*1
 Wall bracket *1
 User manual *1
 Power adapter *1
1.2 Interface Introduction
1) LED status light: Indicates the current working status of the machine, see Table 1 of
Section 4.1
2) Power interface
3) Reset button: Long press to restore the device to factory settings.
4) Temperature and humidity sensor interface: Used to connect the bottom and
transmit temperature and humidity data.
5) Photosensitive sensor: Used for automatic switching of night vision.
6) Microphone
7) Lens
LED status light
Microphone
Temperature&humidity
sensor interface
Power interface
Reset button
Photosensitive sensor
Lens
