Fill the condensate trap to the top with
water and replace the union cap and
gasket.
6.
Loosen the upper union, and slide
the trap over the boiler drain outlet,
and then tighten the upper union nut.
7.
To reinstall the trap pan, tilt and slide the
two tabs under the chassis of the boiler,
and secure with the two wing nuts.
8.
Ensure that the bottom union
cap is hand-tightened to
prevent leakage. Do not use
tools and over-torque.
7.4 Cleaning the condensate trap
