Figure 47. Connector locations for the 8408-44E and 8408-E8E systems
Connector locations for the 9080-MHE, 9080-MME, 9119-MHE, and 9119-MME systems
Learn about connector locations for the 9080-MHE, 9080-MME, 9119-MHE, and 9119-MME systems.
The 9080-MHE, 9080-MME, 9119-MHE, and 9119-MME servers provide cable connector locations via a
SAS port for disk drive enclosures and cable ports for the EMX0 PCIe3 expansion drawer.
52
Power Systems: Installing the 5887 disk drive enclosure
