IBM 655743N - P 92 - 19" CRT Display User Manual

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
6557-03N/03S/43N/43S
AD
7-4
R420 1-216-049-91 RES,CHIP 1K 5% 1/10W
R421 1-216-049-91 RES,CHIP 1K 5% 1/10W
R424 1-216-049-91 RES,CHIP 1K 5% 1/10W
R425 1-216-097-91 RES,CHIP 100K 5% 1/10W
R428 1-216-055-00 RES,CHIP 1.8K 5% 1/10W
R429 1-216-121-91 RES,CHIP 1M 5% 1/10W
R430 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R431 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R432 1-216-049-91 RES,CHIP 1K 5% 1/10W
R434 1-216-025-91 RES,CHIP 100 5% 1/10W
R435 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R436 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R437 1-216-049-91 RES,CHIP 1K 5% 1/10W
R439 1-216-049-91 RES,CHIP 1K 5% 1/10W
R440 1-216-081-00 RES,CHIP 22K 5% 1/10W
R446 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R447 1-216-089-91 RES,CHIP 47K 5% 1/10W
R448 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R448 1-216-077-00 RES,CHIP 15K 5% 1/10W
R449 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R450 1-216-041-00 RES,CHIP 470 5% 1/10W
R451 1-216-129-00 RES,CHIP 2.2M 5% 1/10W
R452 1-216-041-00 RES,CHIP 470 5% 1/10W
R453 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R456 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R457 1-216-073-00 RES,CHIP 10K 5% 1/10W
R458 1-219-749-91 CARBON 10K 5% 1/2W
R459 1-216-025-91 RES,CHIP 100 5% 1/10W
R460 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R461 1-211-885-21 METAL 2.2M 5% 1W
R462 1-216-091-00 RES,CHIP 56K 5% 1/10W
R463 1-211-895-11 METAL 10M 10% 1/4W
R464 1-216-097-91 RES,CHIP 100K 5% 1/10W
R465 1-216-097-91 RES,CHIP 100K 5% 1/10W
R466 1-216-049-91 RES,CHIP 1K 5% 1/10W
R467 1-216-049-91 RES,CHIP 1K 5% 1/10W
R469 1-216-073-00 RES,CHIP 10K 5% 1/10W
R480 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R481 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R486 1-216-049-91 RES,CHIP 1K 5% 1/10W
R487 1-216-025-91 RES,CHIP 100 5% 1/10W
<SPARK GAP>
SG101 1-517-499-21 GAP, SPARK
SG201 1-517-499-21 GAP, SPARK
SG301 1-517-499-21 GAP, SPARK
SG401 1-517-499-21 GAP, SPARK
SG402 1-519-422-11 GAP, SPARK
********************************************************************************
* 8-933-313-00 D BOARD, COMPLETE
****************************
2-371-561-00 BUSHING (P), INSULATING (IC502)
4-060-842-01 SHEET, INSULATING (IC502)
4-060-844-01 SHEET, INSULATING (IC1504)
4-382-854-11 SCREW (M3X10), P, SW (+)
(IC502, IC603,IC1504, Q514, Q530, Q531,
Q605, Q905, Q906,D511,D601,D617,D622,
R539, R919)
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
<CAPACITOR>
C001 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C002 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C003 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C004 1-104-664-11 ELECT 47MF 20% 25V
C005 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C006 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C007 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C008 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C009 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C010 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C011 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C012 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C013 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C014 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C015 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C016 1-104-664-11 ELECT 47MF 20% 25V
C017 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C018 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C020 1-126-964-11 ELECT 10MF 20% 50V
C021 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C022 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C023 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C024 1-104-664-11 ELECT 47MF 20% 25V
C025 1-104-664-11 ELECT 47MF 20% 25V
C026 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C027 1-126-961-11 ELECT 2.2MF 20% 50V
C029 1-126-935-11 ELECT 470MF 20% 16V
C030 1-137-372-11 FILM 0.022MF 5% 50V
C031 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C036 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C037 1-164-695-11 CERAMIC CHIP 0.0022MF 5% 50V
C038 1-126-960-11 ELECT 1MF 20% 50V
C040 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C041 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C042 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C043 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C044 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C045 1-104-760-11 CERAMIC CHIP 0.047MF 10% 50V
C046 1-104-760-11 CERAMIC CHIP 0.047MF 10% 50V
C047 1-104-760-11 CERAMIC CHIP 0.047MF 10% 50V
C048 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C049 1-104-760-11 CERAMIC CHIP 0.047MF 10% 50V
C050 1-136-173-00 FILM 0.47MF 5% 50V
C051 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
