AS/400
Prompt AS/400 Parameter
5494
AS/400
Value 5494 Value NotesField Subfield
Link type LINKTYPE AA - *LAN 4 5494 configuration values must
match the values specified for
the LINKTYPE parameter on the
CRTCTLAPPC command. For
advanced program-to-program
communications (APPC)
controllers that specify
LINKTYPE(*SDLC), the value
specified in the 5494
configuration must be
compatible with the physical
interface (INTERFACE
parameter) specified on the
CRTLINSDLC command.
Select 4 for the network
connections.
Example: Connecting AS/400 to a 5494 controller connected by token-ring
Configuration parameters must be coordinated when you connect an AS/400 system to a 5494 controller
that is connected by token-ring.
The following diagram shows the AS/400 parameters and 5494 parameters that need to match when you
use token-ring.
Chapter 7. Communicating with remote workstation controllers 43
