IBM BladeCenter HS22 User Manual

Installing a memory module
Use these instructions to install memory modules in the blade server.
The blade server has a total of twelve direct inline memory module (DIMM) slots.
The blade server supports very low profile (VLP) DDR3 DIMMs with error code
correction (ECC) in 1 GB, 2 GB, 4 GB, 8 GB, and 16 GB capacities. For a current list
of supported DIMMs for the blade server, see http://www.ibm.com/servers/
eserver/serverproven/compat/us/.
After you install or remove a DIMM, you must change and save the new
configuration information by using the Setup utility. When you turn on the blade
server, a message indicates that the memory configuration has changed. Start the
Setup utility and select Save Settings (see “Setup utility menu” on page 56 for
more information) to save changes.
The memory is accessed internally through the system using six channels. Each
channel contains two DIMM connectors. The following table lists each channel and
which DIMM connectors belong to the channel.
Table 2. Memory channel configuration
Memory channel DIMM connector
Channel 0 DIMM connector 1 and 2
Channel 1 DIMM connector 5 and 6
Channel 2 DIMM connector 3 and 4
Channel 3 DIMM connector 7 and 8
Channel 4 DIMM connector 11 and 12
Channel 5 DIMM connector 9 and 10
Depending on the memory mode that is set in the Setup utility, the blade server
can support a minimum of 1 GB and a maximum of 48 GB of system memory on
the system board in a blade server with one processor. If two microprocessors are
installed, the blade server can support a minimum of 2 GB and a maximum of 96
GB of system memory. There are two different memory modes:
v Independent channel mode: Independent channel mode gives a maximum of 96
GB of usable memory with one CPU installed, and 192 GB of usable memory
with 2 CPUs installed (using 16 GB DIMMs). The DIMMs can be installed
without matching sizes. See the table below for the memory installation order.
Table 3. System memory configuration for independent channel mode (1 microprocessor)
Installed
memory
DIMM socket
123456789101112
1 DIMM X
2 DIMMs X X
3 DIMMs X X X
4 DIMMs X X X X
5 DIMMs X X X X X
6 DIMMs X XXXXX
Chapter 3. Installing options 29

IBM BladeCenter HS22 Specifications

General

Tcase	76.2 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBZ8
Processor cache	12 MB
Processor cores	6
Processor model	E5649
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	12
Processor codename	Westmere EP
Processor frequency	2.53 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	1333 MHz
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	19
Maximum number of SMP processors	2
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066/1333
Memory channels supported by processor	Triple
Memory bandwidth supported by processor (max)	32 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1
HDD interface	Serial Attached SCSI (SAS)
Total storage capacity	0 GB
Maximum storage capacity	1 TB
Number of HDDs installed	0
Internal memory	12 GB
Memory clock speed	- MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	3 x 4 GB
Graphics card	G200eV
Graphics card memory type	GDDR2
Networking features	Gigabit Ethernet
PS/2 ports quantity	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Compatible operating systems	Microsoft Windows RedHat, SUSE, VMware Oracle Solaris
Chassis type	Rack (1U)
Processor ARK ID	52581
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	446 mm
Width	245 mm
Height	29 mm
Weight	5400 g
