IBM E74 Service Manual

- 24 -
EXPLODED VIEW PARTS LIST
Ref. No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
a
b
c
Part No.
3091TKC061R
6318L17006B
or 6318L17005B
3809TKC035U
3043TKK074H
339-002H
6140TC3004A
6174T11005A
6620TKB002A
or 6620TKB002B
6850TA9009F
6871TST317F
4950TKS169D
4930TKK031C
4810TKK171A
4810TKK204C
3313T17306A
6871TMT428A
332-112F
4001TKK004E
332-095B
Description
CABINET ASSEMBLY, CB777G IBM C055 E74 320T 9930 BK SP LOCAL
CDT(CIRC), M41LFQ803X 55QLUD LG-PHILIPS 70KHZ 29.1MM FST GREEN
CDT(CIRC), M41LFQ803X 55QLAA LG-PHILIPS 70KHZ 29.1MM FST GREEN
BACK COVER ASSEMBLY, CB777G C035 320T 9930 BK IBM SP LOCAL
TILT SWIVEL ASSEMBLY, CB777G T053/B046 320T 9930 BK IBM SP LOCAL
SCREW ASSY, PHP+5*20(FZMY)+GW18 NEW TYPE
COIL,DEGAUSSING, 1090MM 16.5OHM 0.4MM 110T 17" WITH EARTH
FBT (FLY BACK TRANSFORMER), CF2077LG273A LIEN CHANGE 17"
SOCKET(CIRC),POWER, BAE EUN AC UNIVERSAL 3PIN BLACK
SOCKET(CIRC), POWER, SA-4S HUA JIE AC UNIVERSAL 3PIN BLACK
CABLE, D-SUB, UL20276-9C(5.8MM) AT 1560MM BLACK 9930 TC170H DM
PWB(PCB) ASSEMBLY, SUB, CB777H CONTROL TOTAL BRAND LGESP CKD
METAL, SHIELD BOTTOM "H"CHASSIS(C-CKD)
HOLDER, PCB FIX , PC+ABS
BRACKET, CB777F SUPPORTER CDT
BRACKET, H-CHASSIS HOLDER FBT, A-CKD
MAIN TOTAL ASSEMBLY, E74H IBM CA-119
PWB(PCB) ASSEMBLY, MAIN, E74H KLBRMS IBM CA-119 TOTAL
SCREW, DRAWING, D3.5 L10.0 MSWR/FZMY +SW3.5+RW3.5
SCREW ASSEMBLY, TAPTITE P TYPE D3.0 L10.0 MSWR/FZMY SW3+RW10
SCREW, DRAWING, PZP+3*10(MSWR/FZMY)

IBM E74 Specifications

General

Brand	IBM
Model	E74
Category	Monitor
Language	English
