IBM E74 Service Manual

- 25 -
DATE: 2003. 3. 28.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C201 0CN1040K949 0.1M 50V Z F TA52
C301 0CK1040K945 0.1UF 50V Z F TR
C302 0CK1040K945 0.1UF 50V Z F TR
C303 0CK1040K945 0.1UF 50V Z F TR
C305 181-288C MKT 100V 224JTR PHS 26224
C306 0CE107CF638 “100UF SHL,SD 16V M FM5 TP 5”
C307 0CK1040K945 0.1UF 50V Z F TR
C308 0CK1040K945 0.1UF 50V Z F TR
C309 0CK1040K945 0.1UF 50V Z F TR
C310 0CE106CF638 “10UF SHL,SD 16V M FM5 TP 5”
C311 0CK1040K945 0.1UF 50V Z F TR
C312 0CK1040K945 0.1UF 50V Z F TR
C313 0CE476CH638 “47UF SHL,SD 25V M FM5 TP 5”
C314 0CK1010K515 100PF 50V K B TR
C315 0CK10202515 1000PF D 2KV 10% TR B(Y5P)
C325 0CK1040K945 0.1UF 50V Z F TR
C326 0CK1010W515 100P 500V K B TS
C327 0CK10302940 0.01M 2KV Z F S
C328 0CK10302945 0.01UF 2KV Z F TR
C330 181-288E MKT 100V 474JTR PHS 26474
C331 0CC2200W415 22PF 500V J NP0 TR
C332 0CK10301945 10000PF D 1KV Z F(Y5V) TR
C346 0CE475CP638 “4.7UF SHL,SD 160V M FM5 TP 5”
C380 0CE107CF638 “100UF SHL,SD 16V M FM5 TP 5”
C384 0CC1500K415 15P 50V J NP0 TP
C388 0CC1500K415 15P 50V J NP0 TP
C389 0CE475CP638 “4.7UF SHL,SD 160V M FM5 TP 5”
C390 0CK10301945 10000PF D 1KV Z F(Y5V) TR
C397 0CE107CF638 “100UF SHL,SD 16V M FM5 TP 5”
C401 0CK1040K945 0.1UF 50V Z F TR
C402 0CE476CF638 “47UF SHL,SD 16V M FM5 TP 5”
C403 0CK1040K945 0.1UF 50V Z F TR
C406 0CK1010K515 100PF 50V K B TR
C407 0CK1010K515 100PF 50V K B TR
C408 0CK1040K945 0.1UF 50V Z F TR
C409 0CK1010K515 100PF 50V K B TR
C410 0CK1010K515 100PF 50V K B TR
C416 0CE475CK638 “4.7UF SHL,SD 50V M FM5 TP 5”
C501 0CE106CF638 “10UF SHL,SD 16V M FM5 TP 5”
C599 0CE225CK638 “2.2UF SHL,SD 50V M FM5 TP 5”
C601 0CE477CF618 470UF SHL 16V M FL TP5
C603 0CE227CK618 220U SHL 50V M FL TP5
C606 0CQ4721N419 0.0047U 100V J POLY NI TP5
C611 0CE477CF618 470UF SHL 16V M FL TP5
C613 181-288Q MKT 100V 154JTR PHS26154
C614 0CE475CK638 “4.7UF SHL,SD 50V M FM5 TP 5”
C615 0CQ4721N419 0.0047U 100V J POLY NI TP5
C618 0CK1040K945 0.1UF 50V Z F TR
C701 181-288B MKT 100V 104JTR PHS26104
C702 0CE476CK638 “47UF SHL,SD 50V M FM5 TP 5”
C703 0CK8210K515 820P 50V K B TS
C704 0CQ1031N419 0.01U 100V J POLY NI TP
C705 0CE475CK638 “4.7UF SHL,SD 50V M FM5 TP 5”
DATE: 2003. 3. 28.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C706 0CE105CK638 “1UF SHL,SD 50V 20% FM5 TP 5”
C708 0CE227CH638 “220UF SHL,SD 25V M FM5 TP 5”
C709 0CE225CK638 “2.2UF SHL,SD 50V M FM5 TP 5”
C710 181-288Q MKT 100V 154JTR PHS26154
C711 181-288E MKT 100V 474JTR PHS 26474
C712 181-288B MKT 100V 104JTR PHS26104
C713 0CK2210K515 220P 50V K B TS
C714 0CE107CF638 “100UF SHL,SD 16V M FM5 TP 5”
C715 181-288N MKT 100V 103JTR PHS86103
C717 0CE476CF638 “47UF SHL,SD 16V M FM5 TP 5”
C719 0CZZTAB001F SHL-BP SYE / SWE 50V 3.3UF 2
C720 0CK27101515 270P 1KV K B TS
C722 181-303R 304J 31.0*21.0*13.0*20.0 250
C723 181-305C 154J 19.0*14.0*8.0*10.0 250V
C724 0CK1040K945 0.1UF 50V Z F TR
C725 0CK1510W515 150PF 500V K B TR
C726 181-305H 394J 19.0*19.0*12.0*10.0 250
C727 0CN1040K949 0.1M 50V Z F TA52
C728 0CQ5621N419 5600P 100V J POLY NI TP
C729 181-305L 684J 26.0*19.0*12.5*15.0 250
C730 0CN1040K949 0.1M 50V Z F TA52
C731 0CBZTBU004H 5600PF D 2.5KV H M/PP NI FM2
C732 181-288N MKT 100V 103JTR PHS86103
C733 0CBZTBU003H 362J 20.0*12.0*7.0*10.0 800V
C734 0CE2266F618 22M SMS 16V M FM5 TP(5)
C736 0CQ2721N419 2700PF 100V J PE NI TP
C737 0CK10102515 100PF D 2KV 10% B(Y5P) TR
C738 181-302L 682J 19.5*12.0*7.0*10.0 250V
C739 0CE106EK638 10UF KMG 50V M FM5 TP 5
C740 0CE227CL618 220U SHL 63V M FL TP5
C741 0CZZTFT002B ECQV1H154JZ3 154J 50V TP5.0
C742 181-288K MKT 100V 683JTR PHS26683
C743 0CE334CK638 “0.33UF SHL,SD 50V 20% TP 5 F”
C744 0CZZTAB005A SMSHR SYE / SWE 160V 47UF 20
C745 0CK5610W515 560P 500V K B TS
C746 0CK3310W515 330P 500V K B TS
C747 181-288D MKT 100V 473JTR PHS26473
C748 0CK1510W515 150PF 500V K B TR
C749 0CE2256R638 2.2000UF SMS 250V M FM5 TP5
C750 0CK1040K945 0.1UF 50V Z F TR
C751 181-288J MKT 100V 563JTR PHS26563
C752 0CQ4721N419 0.0047U 100V J POLY NI TP5
C753 0CQ1021N419 1000P 100V J POLY NI TP
C754 0CC4700W405 47PF 500V J SL TP
C759 0CQ1821N419 1800P 100V J POLY NI TP
C767 0CK10301945 10000PF D 1KV Z F(Y5V) TR
C771 0CK10301945 10000PF D 1KV Z F(Y5V) TR
C781 0CK1030K945 0.01UF 50V Z F TR
C789 0CK3310W515 330P 500V K B TS
C801 0CK1040K945 0.1UF 50V Z F TR
C802 0CE106CK638 “10UF SHL,SD 50V M FM5 TP 5”
C805 0CE106CK638 “10UF SHL,SD 50V M FM5 TP 5”
C901 0CBZTBU002A BULK PCX2 335 224K
C902 0CBZTBU002A BULK PCX2 335 224K
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
CAPACITORS
