Instructions for Model 820
Choose from the following options:
v If there is no memory card in slot location M01 or M02, then any one of the memory expansion cards
on the processor card in location M03 may be the failing item. See the Locations — Model 820 to
identify the locations, type number, and remove and replace procedure for the memory expansion cards.
v If there is a memory card in slot location M01 or M02, then any one of the memory expansion cards in
any memory card slot, locations M01 or M02, may be the failing item. Or a memory card in location
M01 or M02, may be the failing item. See the Locations — Model 820 to identify the locations, type
number, and remove and replace procedure for the memory expansion cards and memory cards.
Instructions for Model 825
The memory cards are plugged directly onto the processor cards. The processor cards are located in
locations C13, M01, and M02. Any one of the memory cards in slot locations A through H on any
processor card may be the cause of the problem. See Locations — Model 825 to identify the locations,
type number, and remove and replace procedure for the memory cards.
Table 2. Memory locations for Model 825
Reference code Location of failure
B428 x010 memory in location C13 - C
B428 x011 memory in location C13 - A
B428 x012 memory in location C13 - D
B428 x013 memory in location C13 - B
B428 x014 memory in location C13 - G
B428 x015 memory in location C13 - E
B428 x016 memory in location C13 - H
B428 x017 memory in location C13 - F
B428 x018 memory in location M01 - C
B428 x019 memory in location M01 - A
B428 x01A memory in location M01 - D
B428 x01B memory in location M01 - B
B428 x01C memory in location M01 - G
B428 x01D memory in location M01 - E
B428 x01E memory in location M01 - H
B428 x01F memory in location M01 - F
B428 x020 memory in location M02 - C
B428 x021 memory in location M02 - A
B428 x022 memory in location M02 - D
B428 x023 memory in location M02 - B
B428 x024 memory in location M02 - G
B428 x025 memory in location M02 - E
B428 x026 memory in location M02 - H
B428 x027 memory in location M02 - F
280 iSeries: iSeries Server 270, 800, 810, 820, 825, 830, 840, 870, 890, SB2, and SB3 Hardware Problem Analysis and
