Figure 85. Installing the service access cover

For a stand-alone system, complete the following steps. Refer to Figure 86 on page 90.

a. Slide the cover (B) on to the system unit as shown.

b. Close the latch release (A) by pushing it in the direction shown.

Control panel cables for the 9009-41A, 9009-42A, or 9223-42H

Questions and Answers:

Need help?

Do you have a question about the IBM Power System 9009-41A and is the answer not in the manual?

IBM Power System 9009-41A Specifications

General

Processor	POWER9
Memory slots	16
Form factor	4U
Operating systems supported	AIX, IBM i, Linux
Processor cores	4
Processor threads	32
Processor speed	2.8 GHz
Maximum memory	1024 GB
Storage	SAS SFF Gen3 HDD/SSD, NVMe SSD
