Figure 74. Control panel cable path for a rack-mounted system
4. For a stand-alone system, insert the control panel and cable into the system as shown in Figure 75 on
page 79 and Figure 76 on page 80.
Pass the cable along the channel next to the disk drive backplane. Secure the cable into the clips
along the channel.
78
Power Systems: Power Systems: Control panel

IBM Power System 9009-41A Specifications

General

Processor	POWER9
Memory slots	16
Form factor	4U
Operating systems supported	AIX, IBM i, Linux
Processor cores	4
Processor threads	32
Processor speed	2.8 GHz
Maximum memory	1024 GB
Storage	SAS SFF Gen3 HDD/SSD, NVMe SSD
