7. Install a drawer stop (2), on each side at the front of the rack to prevent the drawer
from sliding out the front. Use six screws (1) and four nut clips (3) to attach the
drawer stops. See the following figure.
8. Replace the parts that you removed earlier:
a. Both power supplies
b. Front bezel
1
2
3
2
Chapter 1. Setting Up the System 11
