CEC Drawer Attached to Three I/O Drawers
CEC Drawer
Primary I/O
Drawer
V/S COMM
V/S COMM
Secondary I/O
Drawer
J15 J16
J15 J16
Secondary I/O
Drawer
J15 J16
Chapter 1. Setting Up the System 19
