Note: Depending on the panel type, additional panel support (pedestals) may be required to restore
structural integrity of the panel. Consult the panel manufacturer to insure that the panel can
sustain a concentrated load of 900 lbs. For multiple frame installation it is possible that two
casters will produce concentrated loads as high as 1800 lbs.
7. Use the raised floor diagram on the next page to install the panels in the proper positions.
Note: Panel cutout sizes are optimized for parallel-channel external cables.
11
AA
BB
CC
DD
223344
A
75
(3.0)
75
(3.0)
170
(6.7)
170
(6.7)
450
(17.7)
450
(17.7)
Rack Placement
Panel Cutout Dimensions
B
B
B
B
B
A
A
+
BA
Rack
Entry/Exit
Front
Rear
117 x 403
117 x 403
4.6 x 15.9
4.6 x 15.9
Dimension
(mm) (in)
Rear
Front
(Panel B3)
(Panels
B2, C3)
Raised Floor with 610-mm (24-inch) Floor Panels
Chapter 2. Physical Characteristics of Systems 183
