7024 Entry Deskside PowerPC Server E Series
Dimensions
Height 648 mm 25.5 in.
Width¹ 315 mm 12.4 in.
Depth 450 mm 17.7 in.
Weight
Maximum 25 kg 55 lbs.
Electrical
Power source loading 0.17
(typical in kVA)
Voltage range (V ac) 100 to 127 or 200 to 240 (switchable)
Frequency (hertz) 50 or 60
Thermal output
(typical)
375 Btu/hr
Power requirements
(typical)
110 watts
Power factor 0.5 to 07
Inrush current⁴ 75 amps at 120 V ac, 150 amps at 240 V ac
Maximum altitude 2135 m (7000 ft.)
Temperature
Requirements
Operating
16 to 32°C
(60 to 90°F)
Non-Operating
10 to 43°C
(50 to 110°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 8 to 80% 8 to 80%
Wet Bulb 23°C (73°F) 27°C (80°F)
Noise Emissions² Operating Idle
L
WAd
5.2 bels 5.0 bels
L
pAm
41 dBA 38 dBA
<L
pA
>
m
36 dBA 34 dBA
Impulsive or
prominent discrete
tones
No No
Clearances Front Back Left Right
Install/Air Flow³ 76mm(3 in) 76mm(3 in) 25mm(1 in) 25mm(1 in)
Service 466mm(18 in) N/A N/A N/A
Footprint
3
Width
365mm(14.4 in)
Depth
602mm(23.7 in)
1. Width measurement includes the optional vertical stand.
2. See “Noise Emission Notes” on page 336 for definitions of noise emissions positions.
3. The amount of space needed by the unit during normal operation is indicated by the footprint dimensions.
4. Inrush currents occur only at initial application of power, no inrush occurs during normal power off-on cycle.
58 Site and Hardware Planning Information
