7337 Model 305 DLT Tape Library
Dimensions
Height 23.5 mm 9.25 in.
Width 47.9 mm 18.9 in.
Depth 67.3 mm 26.5 in.
Weight
Minimum 41.8 kg 92 lbs.
Maximum 41.8 kg 92 lbs.
Electrical
Power source loading
(kVA)
0.34
Voltage range (V ac) 100 to 240 (autoranging)
Frequency (hertz) 50 or 60
Thermal output 445 Btu/hr for two drives
Power requirements 130 watts
Power factor TBD
Maximum altitude 2438 m (6000 ft.)
Temperature
Requirements
Operating
10 to 35°C
(50 to 95°F)
Non-Operating
5 to 32°C
(40 to 90°F)
Humidity
Requirements
Operating Non-Operating
(Noncondensing) 20 to 80% 20 to 80%
Wet Bulb 23°C (73.4°F) 46°C (114°F)
Noise Emissions* Operating Idle
L
WAd
5.5 bels 5.14 bels
L
pAm
N/A N/A
<L
pA
>
m
46 dBA 43 dBA
Impulsive or
prominent discrete
tones
No No
* See “Noise Emission Notes” on page 336 for definitions of emissions positions.
324 Site and Hardware Planning Information
