Number of I/O Drawers
(7040-61D)
1.5 GHz 4-way Modules (Cooling Chart Reference)
4-way 8-way 12-way 16-way
1 A B B C
2 A B C C
3 N/A B C D
4 N/A C C D
5 N/A N/A D D
6 N/A N/A D E
7 N/A N/A N/A E
8 N/A N/A N/A F
Number of I/O Drawers
(7040-61D)
1.5 GHz 8-way Modules (Cooling Chart Reference)
8-way 16-way 24-way 32-way
1 A B B C
2 B B C C
3 N/A C C D
4 N/A C D D
5 N/A N/A D E
6 N/A N/A D E
7 N/A N/A N/A F
8 N/A N/A N/A F
Number of I/O Drawers
(7040-61D)
1.7 GHz 8-way Modules (Cooling Chart Reference)
8-way 16-way 24-way 32-way
1 A B C C
2 B B C D
3 N/A C C D
4 N/A C D E
5 N/A N/A D E
6 N/A N/A E E
7 N/A N/A N/A F
8 N/A N/A N/A F
Chapter 2. Physical Characteristics of Systems 197
