IBM System x3500 M4 11
The following memory protection technologies are supported:
ECC
z
Memory mirroring
z
Memory sparing
z
If memory mirroring is used, then DIMMs must be installed in pairs (minimum of one pair per CPU), and
both DIMMs in a pair must be identical in type and size. If memory sparing is used, then DIMMs must be
installed in sets of three, and all DIMMs in the same set must be identical in type and size.
The following table lists memory options available for the x3500 M4 server.
Table 5. Memory options
Part
number
Description Maximum quantity
supported
Standard models
where used
UDIMMs
49Y1403 2GB (1x2GB, 1Rx8, 1.35V) PC3L-10600 ECC DDR3
1333MHz LP UDIMM
16 (8 per CPU) -
RDIMMs
49Y1405 2GB (1x2GB, 1Rx8, 1.35V) PC3L-10600 CL9 ECC
DDR3 1333 MHz LP RDIMM
24 (12 per CPU) -
49Y1406 4GB (1x4GB, 1Rx4, 1.35V) PC3L-10600 CL9 ECC
DDR3 1333 MHz LP RDIMM
24 (12 per CPU) -
49Y1407 4GB (1x4GB, 2Rx8, 1.35V) PC3L-10600 CL9 ECC
DDR3 1333 MHz LP RDIMM
24 (12 per CPU) A2x, B2x
90Y3178 4GB (1x4GB, 2Rx8, 1.5V) PC3-12800 CL11 ECC DDR3
1600MHz LP RDIMM
24 (12 per CPU) -
49Y1397 8GB (1x8GB, 2Rx4, 1.35V) PC3L-10600 CL9 ECC 1333
MHz LP RDIMM
24 (12 per CPU) C2x, C4x, D2x,
F2x, G2x, H2x, J2x
49Y1400 16GB (1x16GB, 4Rx4, 1.35V) PC3L-8500 CL7 ECC
DDR3 1066MHz LP RDIMM
16 (8 per CPU) -
49Y1563 16GB (1x16GB, 2Rx4, 1.35V) PC3L-10600 CL9 ECC
DDR3 1333MHz LP RDIMM
24 (12 per CPU) -
LRDIMMs
90Y3105 32GB (1x32GB, 4Rx4, 1.35V) PC3L-10600 CL9 ECC
DDR3 1333MHz LP LRDIMM
24 (12 per CPU) -
