IBM System x3500 M4 32
Rack cabinets
The x3500 M4 server can be installed in the rack with the Tower to Rack Conversion Kit (81Y7006). The
server supports the rack cabinets listed in the following table.
Table 23. Rack cabinets and Tower to Rack Conversion Kits
Part number Description
Tower to rack conversion kits
81Y7006 Tower to Rack Conversion Kit
Rack cabinets
201886X IBM 11U Office Enablement Kit
93072PX IBM 25U Static S2 Standard Rack
93072RX IBM 25U Standard Rack
93074RX IBM 42U Standard Rack
93074XX IBM 42U Standard Rack Extension
93084EX IBM 42U Enterprise Expansion Rack
93084PX IBM 42U Enterprise Rack
93604EX IBM 42U 1200 mm Deep Dynamic Expansion Rack
93604PX IBM 42U 1200 mm Deep Dynamic Rack
93614EX IBM 42U 1200 mm Deep Static Expansion Rack
93614PX IBM 42U 1200 mm Deep Static Rack
93624EX IBM 47U 1200 mm Deep Static Expansion Rack
93624PX IBM 47U 1200 mm Deep Static Rack
99564RX IBM S2 42U Dynamic Standard Rack
99564XX IBM S2 42U Dynamic Standard Expansion Rack

IBM System x3500 M4 Specifications

General

Form Factor	5U Tower
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
Processor	Intel Xeon E5-2600 series
Memory	Up to 768GB DDR3
Storage	Up to 32 x 2.5" or 8 x 3.5" hot-swap SAS/SATA drives
RAID Support	RAID 0, 1, 5, 10
Network Interface	Four integrated Gigabit Ethernet ports
Power Supply	Redundant 750W
Expansion Slots	Up to 8 PCIe slots
