IBM System x3500 M4 User Manual

IBM System x3500 M4 33
Figure 6 shows the server installed in the Tower to Rack Conversion Kit.
Figure 6. The IBM System x3550 M4 with the Tower to Rack Conversion Kit
Rack options
The server supports the rack console switches and monitor kits listed in the following table.
Table 24. Rack options
Part number Description
Monitor kits and keyboard trays
172317X 1U 17in Flat Panel Console Kit
172319X
1U 19in Flat Panel Console Kit
Console switches
1754D2X IBM Global 4x2x32 Console Manager (GCM32)
1754D1X IBM Global 2x2x16 Console Manager (GCM16)
1754A2X IBM Local 2x16 Console Manager (LCM16)
1754A1X IBM Local 1x8 Console Manager (LCM8)
Console cables
43V6147 IBM Single Cable USB Conversion Option (UCO)
39M2895 IBM USB Conversion Option (4 Pack UCO)
39M2897 IBM Long KVM Conversion Option (4 Pack Long KCO)
46M5383 IBM Virtual Media Conversion Option Gen2 (VCO2)
46M5382 IBM Serial Conversion Option (SCO)

IBM System x3500 M4 Specifications

General

Form Factor	5U Tower
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
Processor	Intel Xeon E5-2600 series
Memory	Up to 768GB DDR3
Storage	Up to 32 x 2.5" or 8 x 3.5" hot-swap SAS/SATA drives
RAID Support	RAID 0, 1, 5, 10
Network Interface	Four integrated Gigabit Ethernet ports
Power Supply	Redundant 750W
Expansion Slots	Up to 8 PCIe slots
