IBM System x3550 M4 Product Guide

IBM System x3550 M4 24
Table 8. RAID controllers and HBAs for internal storage (Part 2: 12 Gbps SAS/SATA)
Part number Feature code Description Maximu
m
supporte
d
Standard
models
where used
12 Gb Controllers
00AE938 A5ND ServeRAID M5225 SAS/SATA Controller for
IBM System x
1 -
46C9114 A45W ServeRAID M1215 SAS/SATA Controller for
IBM System x
1 -
46C9110 A3YZ ServeRAID M5210 SAS/SATA Controller 1 -
00AE912 A5M0 N2225 SAS/SATA HBA for IBM System x 1 -
47C8675 A3YY N2215 SAS/SATA HBA for IBM System x 1 -
Hardware upgrades
47C8668 A3Z3 ServeRAID M5200 Series 4GB Flash/RAID 5
Upgrade for IBM Systems
1 -
47C8656 A3Z0 ServeRAID M5200 Series 1GB Cache/RAID 5
Upgrade
1 -
47C8660 A3Z1 ServeRAID M5200 Series 1GB Flash/RAID 5
Upgrade
1 -
47C8664 A3Z2 ServeRAID M5200 Series 2GB Flash/RAID 5
Upgrade
1 -
Feature on Demand upgrades
00AE930 A5H5 ServeRAID M1200 Zero Cache/RAID 5
Upgrade for IBM Systems FOD
1 -
47C8708 A3Z6 ServeRAID M5200 Series Zero Cache/RAID 5
Upgrade
1 -
47C8706 A3Z5 ServeRAID M5200 Series RAID 6 Upgrade 1* -
47C8710 A3Z7 ServeRAID M5200 Series Performance
Accelerator
1* -
47C8712 A3Z8 ServeRAID M5200 Series SSD Caching
Enabler
1* -
* Requires cache memory upgrade (47C8656, 47C8660, or 47C8664).
The ServeRAID H1110 adapter has the following specifications:
Four internal 6 Gbps SAS/SATA ports

One x4 mini-SAS internal connector (SFF-8087)

Up to 6 Gbps throughput per port

Based on LSI SAS2004 6 Gbps RAID on Chip (ROC) controller

PCIe x4 Gen 3 host interface

Supports RAID 0, 1, 1E, and 10

Connects to up to four SAS or SATA drives


IBM System x3550 M4 Specifications

General

Processor	Intel Xeon E5-2600 series
Chipset	Intel C600 series
Memory	Up to 768 GB
Storage	Up to 8 x 2.5" hot-swap drives
Form Factor	1U rack
Power Supply	750 W AC
Network Interface	4 x 1 GbE
RAID Support	RAID 0, 1, 10
Expansion Slots	3 x PCIe 3.0 slots
Operating System Support	Windows Server, RHEL, SUSE, VMware
Management	Integrated Management Module II (IMM2)
