IBM T541 User Manual

DATE: 2002. 5. 27.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C733 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C801 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C804 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) SM
C807 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C808 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C809 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) SM
C810 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) SM
C811 0CH3105F946 1UF 16V Z F 2012 R/TP
C812 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C813 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C814 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C815 0CH8107F611 100UF 16V M 85STD(CYL) R/TP
C816 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C817 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C818 0CH8107F611 100UF 16V M 85STD(CYL) R/TP
C820 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C821 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C822 0CE107WF6DC 100UF MVK 16V 20% R/TP(SMD) SM
C823 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C824 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C827 0CH3105F946 1UF 16V Z F 2012 R/TP
C828 0CH8107F611 100UF 16V M 85STD(CYL) R/TP
C829 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C830 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C831 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C832 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C833 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C834 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C835 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
D201 0DS181009AA KDS181 TP KEC SOT-23 80V 300
D701 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D702 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D703 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D704 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D705 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D706 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D707 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D708 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D709 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D710 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D711 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D712 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D713 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
D714 0DS226009AA KDS226 TP KEC SOT-23 80V 300M
ZD501 0DZ910009FE UDZS 9.1B TP ROHM - - 9.1V - -
ZD701 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD702 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD703 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD704 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD705 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
U101 0IPRPS5002A SIL141BCT80 SILICON IMAGE 80P,
U102 0IPRPMR002A MX88L295EC MACRONIX 128P,PQFP
U201 0IPRPMR001A MX88L250EC-X MACRONIX 128P,PQF
U401 0ITH638300B THC63LVDM83R THINE 56P,TSSOP R
U501 0ICS240213A CAT24WC02J-TE13 8P SOP TP 2K I
U502 0IZZTSZ189A MYSON 42P BK OTP LI507N
DATE: 2002. 5. 27.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
U503 0ICS240813B CAT24WC08J-TE13 8P,SOIC R/TP 8
U504 0ICS240213A CAT24WC02J-TE13 8P SOP TP 2K I
U701 0IMO741420B MC74HCT14ADR2 14P,SOIC TP LEVE
U702 0IPH740800H 74F08D 14P,SOIC TP QUAD 2-INPU
U703 0IPH740800H 74F08D 14P,SOIC TP QUAD 2-INPU
U704 0ITI748600N SN74F86DR 14SOIC TP 2-INPUT EX
U801 0TFFC80009A FAIRCHILD FDC6326L R/TP SOT-6
U802 0IRH033000A BA033SFP P/MOLD-5 TP REGULATOR
U803 0IRH033200A BA033FP-E2 MOLD-3 TP REGULATOR
U804 0IRH033200A BA033FP-E2 MOLD-3 TP REGULATOR
U805 0ISS780500H KA78M05-R 3P,D-PAK TP 5V 0.5A
U806 0IPMGON007A NCP1117ST25T3 ON SEMI SOT223 R
U807 0TFFC80009A FAIRCHILD FDC6326L R/TP SOT-6
L101 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L102 6210TCE001K HB-1H2012-260JT CERATEC 2012MM
L103 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
L104 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
L105 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
L201 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
L202 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L203 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L204 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L205 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L501 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L502 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L503 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L504 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L505 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L701 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L705 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L706 6210TCE001P HB-1S2012-121JT CERATECH 2012M
L707 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
L708 6210TCE001S HU-1M2012-121 CERATECH 2012MM
L805 6210TCE001G HH-1M3216-501 CERATEC 3216MM R
Q501 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23 3
Q502 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23 3
Q503 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23 3
Q504 0TR150509AD KTA1505S-Y -T1 TP KEC SOT23
Q505 0TR150509AD KTA1505S-Y -T1 TP KEC SOT23
Q506 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP S
Q507 0IKE704200J KIA7042AF SOT-89 TP 4.2V VOLTA
Q508 0TR162309CA KSC1623 TP SAMSUNG SOT23 NPN
Q509 0TR162309CA KSC1623 TP SAMSUNG SOT23 NPN
Q701 0TR390409AE FAIRCHILD KST3904(LGEMTF) TP S
R101 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R102 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R103 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R104 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R105 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R106 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R107 0RJ1501D677 1.5K OHM 1/10 W 5% 1608 R/TP
R108 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R109 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
- 20 -
DIODEs
ICs
COILs & COREs
TRANSISTOR
RESISTORs
