WIRING DIAGRAM
- 6 -
J4
J1
J702
J702
CN3
CN2
CN1
J3
J2
Connector Ass’y P/No.
: 6631T12002J
Connector Ass’y P/No.
: 6631T11012X
Connector Ass’y P/No.
: 6631T20008X
Connector Ass’y P/No.
: 6631T20008X
