- 19 -
DATE: 2002. 5. 27.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C104 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C105 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C106 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C107 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C108 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C109 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C111 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C112 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C113 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C114 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C115 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C116 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C118 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C120 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C121 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C122 0CH8226F611 22UF 16V M 85STD(CYL) R/TP
C123 0CH8226F611 22UF 16V M 85STD(CYL) R/TP
C124 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C125 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C127 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C128 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C129 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C130 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C131 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C132 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C133 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C134 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C135 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C136 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C137 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C138 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C139 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C140 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C141 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C142 0CC100CK41A 10PF 1608 50V 5% R/TP NP0
C143 0CC100CK41A 10PF 1608 50V 5% R/TP NP0
C144 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C145 0CH8107F611 100UF 16V M 85STD(CYL) R/TP
C146 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C147 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C148 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C149 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C150 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C202 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C203 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C204 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C205 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C206 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C208 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C209 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C210 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C212 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
DATE: 2002. 5. 27.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C213 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C214 0CC150CK41A 15PF 1608 50V 5% R/TP NP0
C215 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C216 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C217 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C218 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C219 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C220 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C222 0CC150CK41A 15PF 1608 50V 5% R/TP NP0
C223 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C224 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C225 0CC680CK41A 68PF 1608 50V 5% R/TP NP0
C403 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C404 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C405 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C406 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C407 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C501 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C502 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C503 0CH8106J691 10UF 35V M 105STD (CYL) R/TP
C504 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C505 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C506 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C507 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C508 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C509 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C510 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C511 0CC180CK41A 18PF 1608 50V 5% R/TP NP0
C512 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C513 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C514 0CH8106F611 10UF 16V M 85STD(CYL) R/TP
C515 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C516 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C517 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C518 0CC180CK41A 18PF 1608 50V 5% R/TP NP0
C519 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C701 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C702 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C705 0CE477EF610 470UF KMG,RD 16V 20% BULK FL
C706 0CE477EF610 470UF KMG,RD 16V 20% BULK FL
C707 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C708 0CC221CK41A 220PF 1608 50V 5% R/TP NP0
C709 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C710 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C711 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C712 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5P
C713 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C714 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C715 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C716 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C719 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C720 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C721 0CC221CK41A 220PF 1608 50V 5% R/TP NP0
C732 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
