IBM T541 User Manual

DATE: 2002. 5. 27.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
RA105 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA106 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA107 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA108 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA109 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA110 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA111 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA112 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA201 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA202 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA203 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA204 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA205 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
RA206 0RHZTCZ001A 100 OHM 1/16 W 5% 3215 R/TP CH
J705 6612TAH003A DJ-023 KSD R/ANGLE LB563B
X201 6202TST001A SX-1 SUNNY ,SMS, 14.31818MHZ ,
X501 6202TST003D HC-49/SM5H KONY CHIP 12 MHZ 30
BD901 0DD360000DB D3SB60 SHINDENKEN
C901 0CBZTBU002C BULK PCX2 335 104M
C902 0CKZTBU006B NK E 332M 250V BK10.0 DA2GYE33
C903 0CKZTBU006B NK E 332M 250V BK10.0 DA2GYE33
C904 0CE108EF630 1000UF KMG 16V M FM5 BULK
C905 0CZZTAB002B KMF 16*35.5 SYE / SWE 400V 82U
C906 0CK10302940 0.01M 5KV Z F S
C907 0CE105EN638 1UF KMG 100V M FM5 TP 5
C908 0CE476EH638 47UF KMG 25V M FM5 TP 5
C909 181-288B MKT 100V 104JTR PHS26104
C910 0CBZTBU002C BULK PCX2 335 104M
C911 0CE108EF630 1000UF KMG 16V M FM5 BULK
C912 0CK1030K945 0.01UF 50V Z F TR
C914 0CE335EK638 3.3UF KMG 50V M FM5 TP 5
C916 181-288C MKT 100V 224JTR PHS 26224
C918 0CE108EF630 1000UF KMG 16V M FM5 BULK
C919 0CE108EF630 1000UF KMG 16V M FM5 BULK
C920 0CKZTBU006B NK E 332M 250V BK10.0 DA2GYE33
C921 181-288L MKT 100V 823JTR PHS26823
C922 0CKZTTA002E EKR3A102K09FK5 SAMWHA 1KV 1000
C923 0CKZTTA002E EKR3A102K09FK5 SAMWHA 1KV 1000
C924 0CE108EF630 1000UF KMG 16V M FM5 BULK
D901 0DD400709CB UF4007 TP G.I DO204AL 1000V 1
D903 0DRGS00341A MBRF20H100CT GENERAL SEMICONDU
D904 0DR400409AB UF4004 TP G.I DO204AL 400V 1A
D906 0DR206000AA MBRF2060CT BK G.I ITO220 60V 2
D908 0DZ620009AP P6KE200A GENERAL SEMICONDUCTOR
D909 0DZ120009AF MTZJ12B TP ROHM-K DO34 500MW 1
F1 430-858C AFC-520 BAE EUN TA
F2 430-858C AFC-520 BAE EUN TA
F901 0FZZTTH001D TIME LAG HBC 3.15A/250V,215 3.
IC901 0IPMGPF006A TOP247F POWER INTEGRATION TO26
IC904 0ISS431000A KA431AZ (LM431AZ)
L901 150-A85F LX31 GET BAR CHOKE,3.3UH,LB886
LF901 6200TZZ001B - 0 BK L/FILTER, 9MH,LG56BP
LF902 6200TZZ001B - 0 BK L/FILTER, 9MH,LG56BP
P901 6620TKB002C BCP031S-A,BAE EUN AC UNIVERSAL
PC901 0ILI817000E LTV-817M B 4P BK PHOTO COUPLER
R901 0RD6803A609 680K OHM 1/2 W (7.0) 5% TA52
DATE: 2002. 5. 27.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R902 0RD1004Q609 1M OHM 1/4 W (3.4) 5% TA52
R903 0RD1004Q609 1M OHM 1/4 W (3.4) 5% TA52
R904 0RD4704Q609 4.7M OHM 1/4 W (3.4) 5% TA52
R905 0RD4704Q609 4.7M OHM 1/4 W (3.4) 5% TA52
R906 0RX4702J609 47K OHM 1 W 5% TA52
R907 0RD0471Q609 4.70 1/4W(3 5% TA52
R908 0RD0681Q609 6.8 OHM 1/4 W (3.4) 5% TA52
R909 0RD3300Q609 330 1/4W(3 5% TA52
R913 0RN1302F409 13K 1/6W 1% TA52
R917 0RD1001Q609 1K 1/4W(3 5% TA52
R920 0RN1302F409 13K 1/6W 1% TA52
R921 0RN2701F409 2.70K 1/6W 1% TA52
R923 0RD1302Q609 13K 1/4W(3 5% TA52
T901 6170TMZ136A EER3016 650UH V-10PIN T541H SI
TH901 6322A00002B SCK-102L THINKING 10OHM 20% 25
J1 6602T12002E 53261-0690 MOLEX 6P 1.25MM R/A
LED1 0DLLT0089AA LITEON LTL-1BEDJ-0C2 TP GREEN/
R1 0RJ8200D677 820 OHM 1/10 W 5% 1608 R/TP
R2 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R3 0RJ8200D677 820 OHM 1/10 W 5% 1608 R/TP
R4 0RJ1501D677 1.5K OHM 1/10 W 5% 1608 R/TP
R5 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
SW1 6600TR1004A ALPS NON 12V VERTICAL 100
SW2 6600TR1004A ALPS NON 12V VERTICAL 100
SW3 6600TR1004A ALPS NON 12V VERTICAL 100
SW4 6600TR1004A ALPS NON 12V VERTICAL 100
SW5 6600TR1004A ALPS NON 12V VERTICAL 100
ZD1 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
ZD2 0DZ560009DA UDZ S 5.6B TP ROHM-K SOD323 20
- 22 -
CONTROL BOARD
OTHERs
POWER BOARD
