IBM ThinkPad A21m - 1140 Fan Assembly

1140 Fan assembly
For access, remove these FRUs, in order:
v “1010 Battery pack” on page 60
v “1050 Hard-disk drive or RF ID adapter” on page 67
v “1060 Ultrabay 2000 device” on page 69
v “1070 Keyboard” on page 71
v “1080 Keyboard CRU insulator” on page 74
v “1090 Hinge cover and clear sheet icon” on page 75
v “1100 Keyboard bezel and speaker” on page 76
Note: Step 1a is for the MT2628-Fxx, Gxx, Pxx, Qxx,
Rxx, Sxx, Txx, Xxx, MT2633-Gxx, Txx, and
MT2629. Other model do not have the screw 1a.
Step Screw (quantity) Torque
1a M2.5 × 4.8 mm, nylon-coated (2) 0.392 Nm
(4 kgfcm)
1 M2.5 × 4.8 mm, nylon-coated (3) 0.392 Nm
(4 kgfcm)
Removing and replacing a FRU
ThinkPad A20m/p, A21m/p and A22m/p 83
