9
9
9
9
StepScrew(quantity)Color
Torque
9
M2×3mm,bighead,nylon-coated(4)
Black0.181Nm
(1.85kgf-cm)
10
Wheninstalling:
Ensurethattheconnectorsareattachedfirmly.
1200Smartcardandsmart-cardcable,orsmart-carddummydoor
Foraccess,removetheseFRUsinorder:
“1010SIM-cardtray”onpage62
“1020Externalbatterypack”onpage62
“1030Keyboardrubbers”onpage63
“1050Basecoverassembly”onpage70
“1130Coin-cellbattery”onpage84
“1180Smart-cardbracket”onpage91
“1190Systemboardandsubcards”onpage92
Chapter9.RemovingorreplacingaFRU95
