IBM THINKPAD L460 - 1160 Thermal Fan Assembly

6
6
Wheninstalling:
Ensurethattheconnectorofthedc-incableisattachedfirmly.
1160Thermalfanassembly
Foraccess,removetheseFRUsinorder:
•“1010SIM-cardtray”onpage62
•“1020Externalbatterypack”onpage62
•“1030Keyboardrubbers”onpage63
•“1050Basecoverassembly”onpage70
Removalstepsofthethermalfanassembly
Notes:
•Loosenthescrews
3inascendingalphabeticalorderasillustrated.Thescrews3cannotberemoved.
•Thescrews3e,3f,and3gareavailableonlyonsomecomputermodels.
1
3d
3a
3c
3e
3b
3f
3g
2
88ThinkPadL460HardwareMaintenanceManual
