Systemboardconnectorsandcables
1 2 3 4 5
6
7
8
910
1113 1214
15
16
17
18
19 20
21
22
Table12.Systemboard
No.
Connector/feature
Internalcablerequired
Cableconnection
1
Batteryconnector(internal)
No
Connecttheremovablebattery
directlytothisconnector.
2
Dockingconnector(internal)
No
Connectthesupporteddocking
stationdirectlytothisconnector.
3
dc-inconnector(internal)
dc-incable
Thepowerconnectorofthe
computercomeswiththedc-in
cable.Connectthecabletothis
connector.
4
Thermalfanconnector(internal)
ThermalfanassemblycableThethermalfanassemblycomes
withcable.Connectthecableto
thisconnector.
52ThinkPadL460HardwareMaintenanceManual
