USBandaudioboardconnectorsandcables
1
2
3
Table13.USBandaudioboard
No.
Connector/feature
Internalcablerequired
Cableconnection
1
USBandaudioboardconnector
(internal)
No
ConnecttheUSBandaudioboard
tothesystemboarddirectly
2
AlwaysOnUSBconnector
(external)
No
InsertUSB-compatibledevices
intotheUSBconenctor;
3
Audioconnector(external)
No
Connectheadphonesoraheadset
with3.5-mm(0.14-inch)4-pole
plugtotheaudioconnector.
VGAboardconnectorsandcables
1 2
Table14.VGAboardconnector
No.
Connector/feature
Internalcablerequired
Cableconnection
1
VGAconnector(external)
No
Connectacompatibleprojector,
externalmonitor,orhigh-definition
televisiontothisconnector
2
VGAboardconnector(internal)
No
ConnecttheVGAboardtothe
systemboarddirectly
Smart-cardconnectorandcable
1
