“1050Basecoverassembly”onpage70
Removalstepsofthespeakerassembly
1
8
2
2
2
2
4
4
4
3
3
3
3
StepScrew(quantity)Color
Torque
3
M2×4mm,bighead,nylon-coated(4)
Black0.181Nm
(1.85kgf-cm)
Wheninstalling:
Ensurethatthespeakerrubbersarewellinstalled.
Ensurethattheconnectorofthespeakerassemblyisattachedfirmly.
Routethecablesasshowninthefollowingillustration.
Attention:Asyouroutethecables,ensurethattheyarenotsubjecttoanytension.Tensioncouldcause
thecablestobedamagedbythecableguides,orawiretobebroken.
