Connecting the card to a terminal or computer
To connect the card to a terminal or computer and start the configuration utility,
complete the following steps:
1. Connect the serial cable that comes with the uninterruptible power supply to the
COM connector on the Web/SNMP Card.
2. Connect the other end of the serial cable into the TTY port on the terminal or
the COM connector on a computer.
3. Open a terminal emulation program and select the applicable serial connection
(such as COM1).
Set the serial line to 9600 baud, no parity, 8 data bits, 1 stop bit, and no flow
control.
4. Turn on the uninterruptible power supply.
5. After a few seconds, press Enter. The Password screen opens. If the screen
does not open, press Enter again.
If you still do not see the Password screen, check the following conditions:
v Make sure that the serial line is set to 9600 baud, no parity, 8 data bits, 1
stop bit, and no flow control.
v If the serial line settings are correct, check the cabling to be sure that all
connections are secure.
v Make sure that the terminal program is on the correct communication port for
the serial connection.
v Make sure that the Web/SNMP card has power (one or more LEDs on the
card is lit) and that the uninterruptible power supply is turned on.
6.
Type your password (the default password is admin) and press Enter. The Main
Menu screen opens.
+===================================================================
| [ ConnectUPS Web/SNMP Card Configuration Utility ]
+===================================================================
Enter Password: *****
+===================================================================
| [ ConnectUPS Web/SNMP Card Configuration Utility ]
+===================================================================
1. Web/SNMP Card Settings
2. Reset Configuration to default
3. Restart Web/SNMP Card
4. UPS Pass-Through
0. Exit
Please Enter Your Choice =>_
Configuring the Web/SNMP card
To configure the Web/SNMP card, complete the following steps:
1. In the Web/SNMP Card Configuration Utility main menu, type 1 to enter the
Settings screen.
28 UPS 3000 LV and UPS3000 HV: Installation and Maintenance Guide
