IBM System x3650 M4 26
Table 7. Internal storage expansion options (Part 2)
12 Gb SAS/SATA (Support is planned for later in 2013)
None* A460 x3650M4 8x 2.5" HS HDD Assembly Kit for 12Gb RAID
For CTO only. First set of eight 2.5-inch hot-swap bays for 12 Gb drive

connectivity.
Requires either one M5210 or one N2215.

1
00Y7627 A461 x3650M4 16x 2.5" HS HDD Assembly Kit with Expander for 12Gb RAID
For models with eight 12 Gb 2.5-inch hot-swap bays, adds eight more 12

Gb bays for a total of 16 2.5-inch hot-swap HDD bays.
This option includes a SAS expander card that is mounted on an HDD

backplane, and it does not consume a PCIe slot.
Includes internal cables.

Requires either one M5210 or one N2215.

1
00Y7626 A462 x3650M4 16x 2.5" HS HDD Assembly Kit for 12Gb RAID
For models with eight 6 Gb 2.5-inch hot-swap bays, adds eight 12 Gb

bays for a total of 16 2.5-inch hot-swap HDD bays.
Does not include a SAS expander. (Eight 6 Gb bays are connected to the

integrated M5110e.)
Includes internal cables.

Requires either one M5210 or one N2215. (Eight 12 Gb bays are

connected to the M5210 or N2215.)
1
* These configurations are only available via CTO and special bid.

IBM x3650 M4 Specifications

General

Processor	Intel Xeon E5-2600 series
Processor Sockets	2
Memory Slots	24 DIMM slots
Form Factor	2U Rack
Memory	Up to 768GB
Network Interface	4 x 1 GbE
RAID Support	RAID 0, 1, 5, 6, 10
Remote Management	Integrated Management Module II (IMM2)
Chipset	Intel C600 series chipset
Expansion Slots	6 PCIe 3.0 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Storage	Up to 32 TB
