IBM System x3650 M4 35
IBM UltraSlim Enhanced SATA Multi-Burner (46M0902) supports the same media and speeds for reading
as DVD-ROM (46M0901). This drive also supports the following media and speeds for writing:
CD-R 24X

CD-RW 4X

High Speed CD-RW 10X

Ultra Speed CD-RW 16X

Ultra Speed Plus CD-RW 16X

DVD-R 8X

DVD-R DL 6X

DVD+R 8X

DVD+R DL 6X

DVD-RW 6X

DVD+RW 8X

DVD-RAM 5X

I/O expansion options
The server supports up to six PCIe slots with different riser cards installed into two riser sockets on the
system planar (one riser socket supports installation of one riser card). Riser 1 supplies slots 1, 2, and 3.
Riser 2 supplies slots 4, 5, and 6. Standard models have Riser card 1 installed with three PCIe 3.0 x8
slots. To enable slots 4 - 6, install a second processor and a second riser card.
The following table lists the PCI riser card options available.
Table 13. PCI riser card options
Part number Feature
code
Description Maximum
supported
69Y5321 A1JU x3650 M4 PCIe Riser Card (3 x8 PCIe slots)
(one included in standard models in Riser socket 1)
2
69Y5322 A1JQ x3650 M4 PCIe Riser Card (1 x16 + 1 x8 PCIe slots) 2
81Y6843 A1JS x3650 M4 PCIX Riser Card (2 PCIX + 1 x16 PCIe slots) 2
90Y5085 A3A1 /
A3L2*
x3650 M4 PCIe Riser Card 2 (1 x16 for GPU + 1 x8 FH/HL Slots) 2
* For CTO orders, order A3L2 for the first riser slot and A3A1 for the second riser slot
The locations of the PCIe slots are shown in the following figure.
Figure 6. Slot dimensions

IBM x3650 M4 Specifications

General

Processor	Intel Xeon E5-2600 series
Processor Sockets	2
Memory Slots	24 DIMM slots
Form Factor	2U Rack
Memory	Up to 768GB
Network Interface	4 x 1 GbE
RAID Support	RAID 0, 1, 5, 6, 10
Remote Management	Integrated Management Module II (IMM2)
Chipset	Intel C600 series chipset
Expansion Slots	6 PCIe 3.0 slots
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Storage	Up to 32 TB
