IBM System x3650 M4 48
External disk storage expansion
The x3650 M4 supports attachment to external storage expansion enclosures, such as the EXP2500
series, by using the ServeRAID M5120 SAS/SATA Controller. The x3650 M4 can also be attached to
supported external storage systems, such as the IBM System Storage® DS3500 series, using a
supported HBA.
Table 26. RAID controllers and options for external disk storage expansion
Part number Feature
code
Description Maximum
supported
Standard models
where used
81Y4478 A1WX ServeRAID M5120 SAS/SATA Controller 4 -
Hardware upgrades for the M5120
81Y4508 A22E ServeRAID M5100 Series Battery Kit 1* -
90Y5046 A2BB x3650 M4 Remote Supercap and Battery Tray** 1 -
81Y4484 A1J3 ServeRAID M5100 Series 512MB Cache/RAID 5
Upgrade
1 -
81Y4487 A1J4 ServeRAID M5100 Series 512MB Flash/RAID 5
Upgrade
1 -
81Y4559 A1WY ServeRAID M5100 Series 1GB Flash/RAID 5 Upgrade 1 -
Feature on Demand upgrades for the M5120
81Y4544 A1X2 ServeRAID M5100 Series Zero Cache/RAID 5
Upgrade
1 -
90Y4318 A2MD ServeRAID M5100 Series SSD Caching Enabler 1 -
90Y4273 A2MC ServeRAID M5100 Series SSD Performance Key 1 -
81Y4546 A1X3 ServeRAID M5100 Series RAID 6 Upgrade 1† -
* The ServeRAID M5100 Series Battery Kit (81Y4508) is only supported with ServeRAID M5100 Series 512MB
Cache/RAID 5 Upgrade (81Y4484).
† The ServeRAID M5100 Series RAID 6 Upgrade (81Y4546) requires 512 MB or 1 GB cache upgrades.
** Cannot be installed if an internal tape drive is installed
The ServeRAID M5120 SAS/SATA Controller has the following specifications:
Eight external 6 Gbps SAS/SATA ports

Two external x4 mini-SAS connectors (SFF-8088)

Supports RAID levels 0, 1, and 10

Supports RAID levels 5 and 50 with optional M5100 Series RAID 5 upgrades

Supports RAID 6 and 60 with the optional M5100 Series RAID 6 Upgrade

Supports 512 MB battery-backed cache or 512 MB or 1 GB flash-backed cache

6 Gbps throughput per port

PCIe x8 Gen 3 host interface

Based on the LSI SAS2208 6 Gbps ROC controller

Supports connectivity to the EXP2512 and EXP2524 storage expansion enclosures

For more information, see the IBM Redbooks Product Guide ServeRAID M5120 SAS/SATA Controller for
IBM System x at:
http://www.redbooks.ibm.com/abstracts/tips0858.html?Open
