IBM System x3650 M4 40
PCIe SSD adapters
The server supports the High IOPS SSD adapters listed in the following table.
Table 18. SSD adapters
Part number Feature code Description Maximum
supported
46C9078 A3J3 IBM 365GB High IOPS MLC Mono Adapter 6
46C9081 A3J4 IBM 785GB High IOPS MLC Mono Adapter 6
90Y4377 A3DY IBM 1.2TB High IOPS MLC Mono Adapter 6
90Y4361 A3MZ IBM 300GB High IOPS MLC Modular Adapter 6
90Y4365 A3N0 IBM 600GB High IOPS MLC Modular Adapter 2
90Y4369 A3N1 IBM 800GB High IOPS MLC Modular Adapter 2
90Y4373 A3N2 IBM 300GB High IOPS SLC Modular Adapter 6
For details about these adapters, see the IBM Redbooks Product Guide
IBM High IOPS MLC Adapters
,
found at the following address:
http://www.redbooks.ibm.com/abstracts/tips0907.html?Open
GPU adapters
The server supports graphics processing units (GPUs) provided riser card 90Y5085 is installed (one or
two depending on the number of GPUs). The server provides up to 225W of external power to each GPU.
The following table lists the supported GPUs.
Table 19. GPU adapters
Part number Feature code Description Maximum
supported
Intel Xeon processor E5-2600 v2 product family
None* A3WH NVIDIA Quadro K600 4
None* A3WJ NVIDIA Quadro K2000 2
Intel Xeon processor E5-2600 product family
81Y6399 A13K NVIDIA Quadro 600 4
94Y5957 4798 NVIDIA Quadro 4000 2**
None* A26Q NVIDIA Quadro 6000 2*
* Available only via CTO or special bid.
** Configurations with two Quadro 4000 adapters are available only via CTO or special bid; certain CPU/memory
limitations apply.
The following configuration rules apply if a GPU is installed:
Configurations with one Quadro 4000 or any quantity of Quadro 6000 adapters are CTO only as they
require additional power and cooling components
