IBM System x3650 M4 41
If three or four Quadro 600 adapters are to be installed, then the second processor must be installed
An air baffle kit and GPU AUX power cables may be required and will be included by the configurator
as needed
If the Quadro 600 is installed, the maximum memory that can be installed is 128 GB.
If Quadro 2000, 4000 or 6000 are installed, a maximum of 16 LRDIMMs or HCDIMMs can be installed
and the total memory installed cannot exceed 512 GB
Further restrictions apply depending on the power supplies installed as described in the Power
supplies section.
Power supplies
The server supports up to two redundant power supplies. Standard models come with one or two power
supplies (model dependent). The following table lists the power supplies.
Table 20. Power supplies
Part number Feature
code
Description Maximum
supported
Standard models
where used
94Y6668 A1H6 IBM System x 550W High Efficiency
Platinum AC Power Supply
2 A2x, B2x, C2x, C4x, 52x,
53x, A3x, B3x, C3x, C5x,
D3x, F3x
94Y6669 A1H5 IBM System x 750W High Efficiency
Platinum AC Power Supply
2 D2x, F2x, G2x, H2x, J2x,
62x, GSx, G3x, H3x, J3x
94Y7631 A39N IBM System x 750W High Efficiency
-48 V DC Power Supply
2 -
94Y6667 A2EB IBM System x 900W High Efficiency
Platinum AC Power Supply
2 L2x, 32x, M2x, 23x, 33x,
43x, 73x, 83x, L3x, M3x
An AC power supply ships standard with one 2.8 m C13 - C14 power cord.
