IBM XT 5160 User Manual

Input Requirements
The nominal power requirements and output voltages are listed in
the following tables.
Voltage @
50/60. Hz ± 3 Hz
Nominal Vac Minimum Vac
Maximum Vac
110
90 137
220/240 180
259
Current: 4.1 A max
at 90
Vac
Input Requirements
Outputs
Nominal
Load
Current
(A)
Regulation
Output(Vdc)
Min Max Tolerance
+5
Vdc
2.3
15.0
+5% to -4%
-5
Vdc
0.0
0.3
+10% to -8%
+12
Vdc 0.4
4.2
+5% to -4%
-12 Vdc 0.0
0.25 +10% to -9%
Vdc Output
Nominal Load Current
(A)
Voltage L imi ts
Output(Vac)
Min
Max Min Max
120
0.0
I
1.0
90 137
220/240
0.0
0.5
180
259
Vac Output
The sense levels of the de outputs are:
Output(Vdc)
Minimum (Vdc)
Sense Voltage
Maximum (Vdc)
Nom ina 1 (Vdc )
+5
Vdc
+4.5 +5.0
+5.5
-5
Vdc
-4.3
-5.0
-5.5
+12 Vdc +10.8 +12.0
+13.2
-12 Vdc -10.2
-12.0
-13.2
Vdc Sense Levels
