s. 11 / 40
– Access point to the commands menu, where the authorised user can execute some clearing-restoring actions.
7. Password access
The password is used to enable or lock the access to setting menu (setup) and to commands menu.
For brand-new devices (factory default), the password management is disabled and the access is free. If
instead the passwords have been enabled and defined, then to get access, it is necessary to enter the
password first, specifying the numeric code through the keypad.
To enable password management and to define numeric codes, see setup menu M15 Password.
There are two access levels, depending on the code entered:
User-Level access (Usr) – Allows clearing of some recorded values and the editing of a restricted
number of setup parameters.
Advanced access level (Adv) – Same rights of the user access plus full settings editing-restoring.
From normal viewing, press □ to recall main menu, select the password icon and press □.(fig..1)
The display shows the screen in picture (fig.2):
Keys ▲and ▼change the selected digit (fig.3)
Keys ◄ and ► move through the digits (fig.4)
Enter all the digits of the numeric code, then move on the key icon.
If the password code entered matches the User access code (password:1000) or the Advanced access
code (password:2000 Available value only if the controller is not installed on the ICAR cabinet) , then
the correspondent unlock message is shown.
Once unlocked the password, the access rights last until:
o the device is powered off.
o the device is reset (after quitting the setup menu).
o the timeout period of two minutes elapses without any keystroke.
To quit the password entry screen press □ key.
fig.1 fig.2 fig.3 fig.4
