Icar RPC 8BGA - Master;Slave Configuration

s. 37 / 40
Static correction
Voltage measure
3 ph-to-ph voltage reading L1-L2, L2-L3, L3-L1
Current measure
L1-L2-L3 phase
Phase angle offset
90°
Capacitor overload current measure
3 Readings on L1-L2, L2-L3, L3-L1
Parameter setting
P02.03 = Three-phase
P02.04 = L1-L2-L3
P02.06 = L1-L2-L3
P02.22 = LV
P02.29 = Fast
Master-Slave configuration
