Johdotusk
aavio
Vakio kolmivaihekytk
entä
KOLMIVAIHEKYTKENTÄ (TYYPILLINEN)
. Kytkentä vakio sovelluksiin.
Jännitemittaus
Vaihe
–
vaihe jännite
L2-
L3
Virtamittaus
L1 vaihe
Vaihekulma asetus
V (L2-L3 )
Ja
(L1)
90°
Capacitor overload
current measure
1 kpl
L2
-
L3
Parametriasetukset
P02.03 =
Kolmivaihe /(Three-
phase)
P02.04 =
L1
P02.06 =
L2-
L3
P02.22 = LV
Muut kytkennät alkuperäise
ssä maualissa
4
6
