Ice i20NBV User Manual

i20NBV 13
OPERATOR MANUAL
TECHNICAL SPECIFICATIONS
MODEL
i20NBV
Brush Assist
DIMENSIONS L
55.7 in / 1,415 mm
DIMENSIONS W
22 in / 560 mm
DIMENSIONS H
44.9 in / 1,140 mm
WEIGHT
210 lbs / 95 Kg
WEIGHT WITH BATTERIES
410 lbs /185 Kg
RECOVERY TANK
CAPACITY
17.2 Gal / 65 L
SOLUTION TANK
CAPACITY
15.9 Gal / 60 L
SQUEEGEE WIDTH
30 in / 762 mm
CLEANING PATH WIDTH
20 in / 500 mm (Disk)
PRODUCTIVITY RATE
19,375 ft
2
/ 1,800 m
2
h
DRIVE SYSTEM
Brush Assisted
TRAVEL SPEED,
MAXIMUM
N/A
MINIMUM AISLE TURN
63 in / 1,600 mm
PAD/BRUSH PRESSURE
65 lbs / 30 Kg Min
SOLUTION FLOW RATE
0 ~ 0.37 Gal / Min
0 ~ 1,400 ml / Min
BRUSH MOTOR
0.75hp / 0.55KW
180 RPM
VIBRATIONS @
CONTROLS
N/A
VACUUM MOTOR
0.54hp / 0.4KW
WATER LIFT - AIR FLOW
45 in / 1,143 mm
BATTERIES
105 AH @ 20 hr rate 12 Volt Requires two
RUN TIME PER CHARGE
2.5 Hours
VOLTAGE DC
24V
DECIBEL RATE AT
OPERATOR'S EAR,
INDOORS
68dB(A)
GRADE LEVEL, MAX
5% (3°)

Ice i20NBV Specifications

General

Brand	Ice
Model	i20NBV
Category	Scrubber
Language	English
