Ice i20NBV User Manual

5 i20NBV
OPERATOR MANUAL
MACHINE COMPONENTS
1. Control Handle
2. Control Handle Start Bail
3. Recovery Tank Support Stand
4. Vacuum Motor, 24VDC
5. Batteries
6. Bucket Fill Port/ Clean-Out Port
7. Solution Tank
8. Motor Hub Lock Pin (Disk Models)
9. Scrub Head Assembly
10. Scrub Head Skirt
11. Wheels, 8 Inch
12. Caster, 3.15 Inch
13. Caster, 2 Inch, Squeegee Blade Adjustment
14. Hose Fill-Port
15. Squeegee Storage Bracket
16. Control panel (see Panel components)
17. Overload protector
18. On-board battery charger / Window
19. Solution Tank Level / Drain Hose
20. Scrub Head Lift Pedal
21. Bumper Rollers
22. Squeegee Assembly
23. Squeegee Vacuum Hose
24. Filter Assembly
25. Ball Valve
26. Squeegee Lift Lever
27. Power cord, on-board Battery charger
28. Recovery Tank Drain Hose
29. Recovery Tank
30. Cover
1 2 3
4
5
6
7
8
9
10
13
14
15
12
11
17
18
19
20
21
22
25
26
27
28
23
24
29
30
16

Ice i20NBV Specifications

General

Brand	Ice
Model	i20NBV
Category	Scrubber
Language	English
