Ice i20NBV User Manual

i20NBV 15
OPERATOR MANUAL
RECOVERY TANK GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO.
REQ'D
1 8136003 RECOVERY TANK COVER 1
2 8131030 DRAIN HOSE 1
3 1962050 CLAMP 1
4 8111300 HINGE ASSEMBLY 2
5 1421618 FLAT WASHER M6×DIA18×1.6 10
6 1021616 HEX BOLT M6×16 10
7 8131020 CABLE 1
8 1221512 SCREW M5×12 2
9 1421510 FLAT WASHER M5×DIA10×1 2
10 8113009 NYLON, CLAMP 2
11 8111008 BRACKET 1
12 1421816 FLAT WASHER M8×DIA16×1.6 2
13 8111007 RECOVERY TANK SUPPORT 1
14 8115404 SLEEVE, P/M 1
15 1021830 HEX BOLT M8×30 1
16 8111015 FLOAT, SHUT-OFF 1
17 2320220 BEND 1
18 1321210 SCREW, SELF-TAPPING, ST4×10 4
19 2320216 COVER, CLEAR 1
20 2320218 GASKET, CLEAR WINDOW 1
21 1221410 SCREW M4×10 2
22 1421409 FLAT WASHER M4.3×DIA9×0.8 4
23 2320217 RUBBER HINGE 1
24 8111022 WARNING LABEL 1
25 2320216A CLEAR COVER, KIT 1
