Ice i20NBV User Manual

i20NBV 24
OPERATOR MANUAL
FRAME & WHEEL GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO.
REQ'D
1 1021820 HEX BOLT M8×20 12
2 1422821 LOCK WASHER M8 6
3 1421824 FLAT WASHER M8×DIA24×2 4
4 8145100 MAIN FRAME 1
5 1421618 FLAT WASHER M6×DIA18×1.6 4
6 1123608 LOCK NUT M6 3
7 8115300 BRACKET, PEDAL LOCKING 1
8 1421124 FLAT WASHER M12×DIA24×2.5 4
9 1123115 LOCK NUT M12 4
10 8119003 SOLENOID VALVE, 24VDC 1
11 1421409 FLAT WASHER M4×DIA9×0.8 2
12 1422411 LOCK WASHER M4 2
13 1221412 SCREW M4×12 4
14 8115004 SPIRNG 1
15 8135010 BRACKET, SQUEEGEE LIFT 1
16 8115005 AXLE SLEEVE 2
17 8135001 PLASTIC THRUST WASHER M12×DIA30×1.5 4
18 1421132 FLAT WASHER M12×DIA32×1.5 4
19 1021230 HEX BOLT M12×30 2
20 1645324 COTTER 3.2×24 1
21 8115003 PIN 1
22 8114511 BALL JOINT M6 1
23 8115001 BRACKET, SQUEEGEE MOUNTING 1
24 8115206 COVER, WHEEL 2
25 1021816 HEX BOLT M8×16 2
26 1421828 FLAT WASHER M8×DIA28×3 2
27
8115200 WHEEL, 8 INCH 2
1612607 BALL BEARING, 6004LU 4
28 1421816 FLAT WASHER M8×DIA16×1.6 10
29 8135405 SHAFT 1
30 1123810 LOCK NUT M8 10
31 8117007 NYLON WASHER DIA12.9×DIA24×2.5 4
32 8115404 BEARING, JOURNAL 2
33 8145001 BUSHING 2
34 1021840 HEX BOLT M8×40 2
35 8115500 CASTER, SWIVEL, 80MM 2
36 8115405 SLEEVE, P/M 2
