Ice i20NBV User Manual

i20NBV 28
OPERATOR MANUAL
SCRUB HEAD LIFT GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO.
REQ'D
1 8137006 NON-SLIP MAT 1
2 8137100 BRACKET, SCRUB HEAD LIFT 1
3 1123810 LOCK NUT M8 5
4 1021830 HEX BOLT M8×30 2
5 1421824 FLAT WASHER M8×DIA24×2 6
6 8117007 NYLON WASHER DIA12.9×DIA24×2.5 4
7 8115404 BEARING, JOURNAL 7
8 8115405 SLEEVE, P/M 2
9 1021825 HEX BOLT M8×25 4
10 1422821 LOCK WASHER M8 4
11 1421816 FLAT WASHER M8×DIA16×1.6 4
12 8117002 LEFT BRACKET 1
13 8117005 SPACER 1
14 8117003 RIGHT BRACKET 1
15 1022860 HEX BOLT M8×60 1
16 8117008 SPRING 1
17 8113109 BEARING, THRUST 2
18 1022845 HEX BOLT M8×45 1
19 8117004 ROLLER 1
20 1421612 FLAT WASHER M6×DIA12×1.6 2
21 1422616 LOCK WASHER M6 2
22 1021616 HEX BOLT M6×16 2
23 8133150 SPRING 1
24 8117001 BRACKET, GUIDE 1
