Ice i20NBV User Manual

i20NBV 32
OPERATOR MANUAL
SOLUTION GROUP
DIA
NO.
PART
NUMBER
DESCRIPTION
NO.
REQ'D
1 8119007 ELBOW G1/2 1
2 8119005 BALL VALVE, G1/2 1
3 8119006 CLAMP 5
4 8119201 TUBING ID=12MM L=70MM 1
5 8119002 ELBOW, TUBING BARB 2
6 8119202 TUBING ID=12MM L=100MM 1
7 8119200 FILTER ASSEMBLY, 40 MESH 1
8 8119101 BASE, FILTER ASSEMBLY 1
9 8119104 SCREEN, FILTER, 40 MESH 1
10 1622760 O RING 1
11 8119102 CAP, FILTER ASSEMBLY 1
12 1421510 FLAT WASHER M5×DIA10×1 2
13 1221512 SCREW M5×12 2
14 8119202 TUBING ID=12MM L=100MM 1
15 1221412 SCREW M4×12 2
16 1422411 LOCK WASHER M4 2
17 1421409 FLAT WASHER M4×DIA9×0.8 2
18 8119003 SOLENOID VALVE, 24VDC 1
19 1962016 CLAMP, 10-16mm 5
20 8119203 TUBING ID=12MM L=135MM 1
21 8119204 TUBING ID=10MM L=360MM 1
22 8116100 WATER SUPPLY TUBE 1
