SERVICE MANUAL FD/HD
14
Outputs:
- Compressor (C). It is still in operation.
- Hot gas valve (GC). It is active during the whole operation launching time.
- Pump (B) and wast water valve (EP) are active during time t6
- Water inlet valve (EW) is activated when time t6 is over (when the pump is stopped)
The operation launching ends when the ice sheet falls down and the curtain micro contact (MC)
is activated.
Two possibilities:
1) MC is active during a time less than t3 when the MC signal stops, the production phase will
start.
2) MC is active during a time more than t3 machine will be stopped due to full storage (all
outputs are switched off / LED LE3 continuously switched on). When the curtain (MC) is closed
again, the initial start-up phase will be re-initiated.
time
description
time
t1
Continuous signal time for water level
5”
t2
Continuous signal time for ice thickness
10”
t3
Open curtain time to activate full storage indication
30”
t4
Start-up timing time
30”
t5
Operation launching maximum time
3.5’
t6
Draining time during operation launching
45”
t7
Production minimum time
5”
t8
Water inlet valve e/w time during production
30”
t9
Water inlet valve e/w timeout
120”
t10
Production maximum timeout
60’
t11
Pump start-up delay time
30”
t12
Draining time at cleaning cycle
60”
t13
Retry time due to water inlet valve e/w timeout
60’
